Specific output AFD according to source or output
display aspect ratio
Table H-3. Specific output AFD according to source display aspect ratio
OutputAFDaccordingtosourcedisplayaspectratio
Display aspect ratio 4:3 14:9 16:9 > 16:9 Other
AFD 911104No AFD
Table H-4. Specific output AFD according to output display aspect ratio
OutputAFDaccordingtooutputdisplayaspectratio
Display aspect ratio 4:3 14:9 16:9 > 16:9 Other
AFD 911104 8
