Chapter 2 ’Installation and Startup’ — Hardware Delivery
50 Electra VS
-
Version 05.10
User Manual - Rev. A
Powering Up
Connect the power cord(s).
6RU and 10RU Device Specifics
If needed, configure the power supply management (refer to the HP
Blade System Enclosure Setup and Installation Guide that corresponds to
the Electra VS, provided on the DVD-ROM).
On initial start-up, use the front panel screen to check the status of the
equipment. To do so:
1.
Press
OK
to activate the display.
2.
Select
Health Summary
from the menu.
3.
Check that all indicators are green.
Performing the Initial Settings
Preparing the Connection
1.
Connect the system private LAN of all the platforms composing the
Electra VS to a single GigE switch:
For blade centers: insert an SFP coupler on interface x1 of the
first internal switch of the blade center, and connect it to the
GigE switch.
For 1RU devices: connect NIC 1 to the GigE switch.
Check that Electra VS is not yet connected to a LAN. Factory-set IP
addresses may cause disturbance (address conflict) on the LAN
when Electra VS is switched on.
Gigabit copper couplers are not fast-Ethernet compliant. Make sure
you use a device that is able to process Gigabit.
