Login and password are required to establish the connection.
2. When the SSH session is established, open the configuration file with
MS Wordpad.
3. Copy all the content of the configuration file (using CTRL-A then
CTRL-C, for example), and copy it into the SSH session.
4. Check that all the instructions are correctly executed (reports are given
on the SSH session).
Description of Configuration Files
Factory Configuration Files
 Factory_config_Flex10_C3000_10.txt
 Factory_config_Flex10_C3000_10D.txt
 Factory_config_Flex10_C7000_10.txt
 Factory_config_Flex10_C7000_10D.txt
When you received the Electra VS, the Flex10 was configured with a
default configuration.
The configuration files listed above contain this factory configuration.
There is two files for the HP C3000 enclosure and for the HP C7000
enclosure depending on flex10 type (Flex10 or Flex10D).
Files to Help You Apply your Own Configuration
 First_part_config_Flex10_CX000.txt
 Last_part_config_Flex10_CX000.txt
When you want to configure the Flex10, it can be easier to reset the
configuration at first and then build your own configuration.
These files will help you do this.
The steps are:
Preliminary
: you shall know exactly the network topology you want to
apply:
 Which Shared Uplink Sets (SUS)?
 Which LANs? Using VLAN tagging?
 Which connectors on the Flex10 panel, for which usage?
 Which blade interfaces, for which LANs? Using VLAN tagging?
The configuration file is also applied to the other Flex10 of the
enclosure.
