Harmonic ELECTRA VS - Electra VS 6 RU (AC 100-240 V Single Phase @ 230 VAC)

Appendix A ’Technical Specifications’ — Hardware Delivery Specifications
502 Electra VS - Version 05.10
User Manual - Rev. A
Electra VS 6RU (AC 100-240V single phase @ 230VAC)
Electra VS 6RU fitted with 8 system storage and processing blades
Table A-53. Electra VS 6RU fitted with 8 blades (AC 100-240V single phase @
115VAC), Dimensions and Weight
Dimensions (H x W x D) 10.4 x 19.1 x 32.977 in / 265 x 485 x 835 mm
Weight G7: 279 lbs / 126 Kg
G8: 252 lbs / 114 kg
Table A-54. Electra VS G7 6RU fitted with 8 blades (AC 100-240V single phase @ 230VAC),
Electrical and Thermal specifications
Idle
@100%
Utilization
Circuit
Max
Total system Inrush
Current
---------------- < 140A @ 115V, < 2ms ----------------------------
Total Input Power (W) 1418 2688 3271
Total Input VA 1447 2743 3338
Total Input Current (A)t 6.29 1.93 14.51
Input Current per cord
(A)
1.05 1.99 2.42
Total Airflow (CFM) 116 222 362
Total Airflow (CMM) 36 10
Heat Dissipating
Power (BTU)
4835 9168 11154
Table A-55. Electra VS G8 6RU fitted with 8 blades (AC 100-240V single phase @ 230VAC),
Electrical and Thermal specifications
Idle
@100%
Utilization
Circuit
Max
Total system Inrush
Current
---------------- < 210A @ 115V, < 2ms ----------------------------
Total Input Power (W) 1076 3027 3704
Total Input VA 1097 3089 3779
Total Input Current (A)t 4.77 13.43 16.43
Input Current per cord
(A)
0.795 2.238 2.739
Total Airflow (CFM) 88 250 395
Total Airflow (CMM) 27 11
