Harmonic ELECTRA VS - Electra VS 10 RU (AC INTL Triple Phase @ 230 VAC)

Appendix A ’Technical Specifications’ — Hardware Delivery Specifications
490 Electra VS - Version 05.10
User Manual - Rev. A
Electra VS 10RU (AC INTL Triple Phase @ 230VAC)
Electra VS 10RU fitted with 16 system storage and processing blades
Table A-21. Electra VS G7 10RU fitted with 16 blades (AC INTL Triple Phase @ 230VAC),
Electrical and Thermal specifications
Idle
@100%
Utilization
Circuit
Max
Total system Inrush
Current
per Branch
---------------- < 210A @ 230V, < 2ms ----------------------------
Total Input Power (W) 2249 4363 5373
Total Input VA 2295 4452 5483
Total Input Current (A)t 3.33 6.45 7.95
Input Current per cord
(A)
1.663 3.226 3.973
Total Airflow (CFM) 179 347 553
Total Airflow (CMM) 510 16
Heat Dissipating
Power (BTU)
7668 14877 18322
Table A-22. Electra VS G8 10RU fitted with 16 blades (AC INTL Triple Phase @ 230VAC),
Electrical and Thermal specifications
Idle
@100%
Utilization
Circuit
Max
Total system Inrush
Current
per Branch
---------------- < 210A @ 230V, < 2ms ----------------------------
Total Input Power (W) 1673 5055 6328
Total Input VA 1707 5158 6457
Total Input Current (A)t 2.47 7.48 9.36
Input Current per cord
(A)
1.237 3.738 4.679
Total Airflow (CFM) 133 387 628
Total Airflow (CMM) 411 18
Heat Dissipating
Power (BTU)
5704 17238 21577
