Appendix A ’Technical Specifications’ — Hardware Delivery Specifications
Electra VS - Version 05.10 491
User Manual - Rev. A
Table A-23. Electra VS G9 10RU fitted with 16 blades (AC INTL Triple Phase @ 230VAC),
Electrical and Thermal specifications
Idle
@100%
Utilization
Circuit
Max
Total system Inrush
Current
per Branch
---------------- < 210A @ 230V, < 2ms ----------------------------
Total Input Power (W) 1901 5565 6692
Tot al In pu t VA - 5677 -
Total Input Current (A)t -8.23 -
Heat Dissipating
Power (BTU)
- 18977 -
Table A-24. Electra VS G9v2 10RU fitted with 16 blades (AC INTL Triple Phase @ 230VAC),
Electrical and Thermal specifications
Idle
@100%
Utilization
Circuit
Max
Total system Inrush
Current
per Branch
---------------- < 210A @ 230V, < 2ms ----------------------------
Total Input Power (W) 1709 5221 6218
Total Input VA - 5328 -
Total Input Current (A)t -7.72 -
Heat Dissipating Power
(BTU)
- 17805 -
Table A-25. Electra VS 10RU fitted with 16 blades ( AC INTL Triple Phase @ 230VAC ),
Dimensions and Weight
Dimensions (H x W x D) 17.4 x 17.6 x 32 in / 442 x 447.04 x 813 mm
Weight 471 lbs / 213 kg
