Appendix A ’Technical Specifications’ — Hardware Delivery Specifications
492 Electra VS - Version 05.10
User Manual - Rev. A
Electra VS10RU fitted with 8 system storage and processing blades
Table A-26. Electra VS G7 10RU fitted with 8 blades (AC INTL Triple Phase @ 230VAC),
Electrical and Thermal specifications
Idle
@100%
Utilization
Circuit
Max
Total system Inrush
Current
per Branch
---------------- < 210A @ 230V, < 2ms ----------------------------
Total Input Power (W) 1353 2512 3081
Total Input VA 1381 2564 3144
Total Input Current (A)t 2 3.72 4.56
Input Current per cord
(A)
1.001 1.858 2.278
Total Airflow (CFM) 111 208 341
Total Airflow (CMM) 36 10
Heat Dissipating
Power (BTU)
4615 8568 10505
Table A-27. Electra VS G8 10RU fitted with 8 blades (AC INTL Triple Phase @ 230VAC),
Electrical and Thermal specifications
Idle
@100%
Utilization
Circuit
Max
Total system Inrush
Current
per Branch
---------------- < 210A @ 230V, < 2ms ----------------------------
Total Input Power (W) 1071 2862 3574
Total Input VA 1093 2921 3647
Total Input Current (A)t 1.58 4.23 5.29
Input Current per cord
(A)
0.792 2.117 2.643
Total Airflow (CFM) 88 237 381
Total Airflow (CMM) 27 11
Heat Dissipating
Power (BTU)
3652 9761 12188
