Harmonic ELECTRA VS - SCTE 35 Conditioner

Chapter 3 ’Web User Graphical Interface’ — Workflow Library
280 Electra VS - Version 05.10
User Manual - Rev. A
SCTE 35 Conditioner
Description
This workflow parses the SCTE 35 sections received and defines the
video frames that will be encoded as IDR frames according with the
following rules:
 reception of a splice insert immediate or a time_signal, no IDR defined
in the encoded stream.
 reception of a not immediate splice insert OUT, determine a video
frame that will be encoded as an IDR.
 reception of a not immediate splice insert IN, determine the video
frame that will be encoded as an IDR.
 When no splice insert IN message is received after a splice insert OUT,
the frame corresponding to return break point in the splice insert IN
will be encoded as an IDR.
Only SCTE 35 splices insert, splices null and time_signal sections are
broadcast at the SCTE 35 output.
The splice_schedule, bandwith_reservation, and private_commands are
filtered.
Figure 3-250. SCTE 35 Conditioner in a workflow
Parameters
There is no configuration parameter.
