Chapter 2 ’Installation and Startup’ — Hardware Delivery
32 Electra VS
-
Version 05.10
User Manual - Rev. A
Hardware Delivery
Chassis Overview
The hardware delivery of the Electra VS product is proposed on three HP
chassis: 1RUx19”, 6RUx19”, or 10RUx19”.
Physical characteristics are as follows:
Hot swappable power supplies
Hot swappable fans
Hot swappable processing units
Hot swappable IP switches
Cooling: front-rear airflow
For more information on the specifications, refer to
Appendix A
’Technical Specifications’
on page 481.
The sections below show the front and rear panels of the devices. For a
full description of the device, refer to the HP documentation:
For a 1RU server, see:
G7: on the DVD-ROM delivered with the Electra VS
G8:
http://www8.hp.com/h20195/v2/GetDocument.aspx?docnam
e=c04128242
G9:
http://www8.hp.com/h20195/v2/GetDocument.aspx?docnam
e=c04447818
For a 6RU server, see:
http://www8.hp.com/h20195/v2/GetHTML.aspx?docname=c04123
379
For a 10RU server, see:
http://www8.hp.com/h20195/v2/GetHTML.aspx?docname=c04229
580
