Harmonic ELECTRA VS - SDI Redundancy Mode

Chapter 3 ’Web User Graphical Interface’ — GUI Description
Electra VS - Version 05.10 189
User Manual - Rev. A
 Align (available in edit mode): aligns the processing components in
the view.
 Remove (available in edit mode): removes the matrix.
 Copy crosspoints : copies the internal crosspoints of the matrix,
that is the links between the inputs and outputs of the matrix, to the
clipboard. You can then paste them into a text document (e.g.
Notepad) or Excel document.
You can find the SDI matrix alarms in the
Logs panel.
SDI Redundancy Mode
If SDI redundancy is managed in the Electra VS, you need to declare the
Redundancy mode in this view. Refer to section ’SDI redundancy
Mode’
on page 160.
The SDI redundancy mode is common to all the SDI redundant jobs
running in the Electra VS.
