Appendix A ’Technical Specifications’ — Common Specifications
Electra VS
-
Version 05.10 515
User Manual - Rev. A
Aspect ratio: WSS, AFD (RP186), AFD Ready (SMPTE 2016), Manual
Connectors:
For ELC-VS-HW-HDSDI-2: BNC connectors.
For ELC-VS-HW-HDSDI-4: DIN 1.0/2.3 rather than larger BNC
connectors. 4 SDI female BNC cables are delivered with the
board.
For ELC-VS-HW-SDI-8: DIN 1.0/2.3 rather than larger BNC
connectors. 8 SDI female BNC cables are delivered with the
board.
For
ELC-VS-HW-3GSDI-4
: DIN 1.0/2.3 rather than larger BNC
connectors. 4 SDI female BNC cables are delivered with the
board.
Extraction of the following SCTE 104 over SMPTE2010 requests and
creation of corresponding SCTE 35 sections (not available on former
dual or quad cards):
Alive_request_data
Splice_request_data :
-
spliceStart_normal
-
spliceStart_immediate
-
spliceEnd_normal
-
spliceEnd_immediate
-
splice_cancel
Splice_null_request
Insert_avail_descriptor_request_data
Insert_descriptor_request_data
Supported splice modes are:
immediate
VITC
UTC
SDI Matrices
The supported SDI matrices all support the Grass Valley protocol.
Table A-60. List of supported SDI matrices
Type Reference Name
8x8 SDI SL-SD0808-N-CP Nevion - VikinX Sublime
8x8 HD-SDI SL-HD0808-N-CP Nevion - VikinX Sublime
16x16 SDI SL-SD1616-N-CP Nevion - VikinX Sublime
