Chapter 2 ’Installation and Startup’ — Hardware Delivery
40 Electra VS
-
Version 05.10
User Manual - Rev. A
Unpacking
Table 2 - 1
lists the accessories that are always shipped with the device.
Use this list to ensure that the order is complete.
More accessories can be delivered depending on options you chose.
Mounting in Rack (Recommendations)
Rack mounting is not mandatory for Electra VS but the ventilation and
safety requirements given in this section must be observed in all cases.
Ventilation
Please refer to the recommendations provided by HP.
Cabling
It is essential to separate the power supply cables from the signal cables.
When facing the rear of the rack (as the device is connected via the rear
panel), the power supply cables must be guided to the right of the chassis
and the signal cables to the left.
Table 2-1. List of accessories delivered with the device
Quantity Description
n
Electra VS blade center or server: 10RU, 6RU or 1RU
n
Bays (if the device is a blade center)
n
Ethernet connectors (if the device is a blade center)
n
Power cords
1
Cable to connect a screen, a keyboard and a mouse to a bay (if
the device is a blade center)
4 or 8
If you ordered an SDI Quad board, 4 SDI female BNC cables
If you ordered an SDI Octo board, 8 SDI female BNC cables
1
Front panel
1
DVD-ROM
