Chapter 1 ’Overview’ — Hardware Delivery
Electra VS
-
Version 05.10 25
User Manual - Rev. A
Hardware Delivery
Chassis
Overview
The hardware delivery of the Electra VS product is proposed on two HP
chassis: 1RUx19” or 10RUx19”.
The Electra VS software can also be deployed on hardware used by
VS7000 product but no more available with Electra VS.
These chassis (6RU chassis, G7/G8 1RU chassis) are still described in this
manual but not available for sale.
Physical characteristics are as follows:
Hot swappable power supplies
Hot swappable fans
Hot swappable processing units
Hot swappable IP switches
Cooling: front-rear airflow
The HP chassis are described in the
Chapter 2 ’Installation and Startup’
,
section
’Hardware Delivery’
on page 25.
Front Panel
1RU Front Panel
Figure 1-2. Electra VS 1RU server front panel
