Chapter 3 ’Web User Graphical Interface’ — GUI Description
Electra VS
-
Version 05.10 225
User Manual - Rev. A
Step 7: Consult the Licenses Required for Job Processing
The licenses required to process jobs are displayed in the
Setup
/
Download
view.
Quantity used
: Number of licenses required to process jobs.
Quantity max
: Number of licenses available on the equipment.
The licenses which are insufficient in number are displayed in orange. It
has no impact on the simulation state but it indicates the number of
licenses that you must acquire to run the system.
Figure 3-196. Setup/Download view - Licenses
The licenses required to process jobs are also present in the exported
XML file.
License
Part number
Quantity
