Harmonic ELECTRA VS - Electra VS 6 RU; Electra VS 6 RU (AC 100-240 V Single Phase @ 115 VAC); Electra VS 6 RU Fitted with 8 System Storage and Processing Blades

Appendix A ’Technical Specifications’ — Hardware Delivery Specifications
Electra VS - Version 05.10 501
User Manual - Rev. A
Electra VS 6RU
Electra VS 6RU (AC 100-240V single phase @ 115VAC)
Electra VS 6RU fitted with 8 system storage and processing blades
Table A-51. Electra VS G7 6RU fitted with 8 blades (AC 100-240V single phase @ 115VAC),
Electrical and Thermal specifications
Idle
@100%
Utilization
Circuit
Max
Total system Inrush
Current
---------------- < 140A @ 115V, < 2ms ----------------------------
Total Input Power (W) 1458 2751 3330
Tot al In pu t VA 1488 2807 3398
Total Input Current (A)t 12.94 24.41 29.55
Input Current per cord
(A)
2.16 4.07 4.92
Total Airflow (CFM) 119 228 369
Total Airflow (CMM) 36 10
Heat Dissipating
Power (BTU)
4972 9381 11355
Table A-52. Electra VS G8 6RU fitted with 8 blades (AC 100-240V single phase @ 115VAC),
Electrical and Thermal specifications in Power Supply Redundancy mode N +1
Idle
@100%
Utilization
Circuit
Max
Total system Inrush
Current
---------------- < 210A @ 115V, < 2ms ----------------------------
Total Input Power (W) 1109 3030 3821
Tot al In pu t VA 1132 3092 3899
Total Input Current (A)t 9.84 26.89 33.90
Input Current per cord
(A)
1.640 4.481 5.651
Total Airflow (CFM) 91 251 408
Total Airflow (CMM) 37 12
Heat Dissipating
Power (BTU)
3781 10333 13030
