Harmonic ELECTRA VS - Electra VS 10 RU (AC NA Triple Phase @ 208 VAC)

Appendix A ’Technical Specifications’ — Hardware Delivery Specifications
486 Electra VS - Version 05.10
User Manual - Rev. A
Electra VS 10RU (AC NA Triple Phase @ 208VAC)
Electra VS 10RU fitted with 16 system storage and processing blades
Table A-11. Electra VS G7 10RU fitted with 16 blades (AC NA Triple Phase @ 208VAC),
Electrical and Thermal specifications
Idle
@100%
Utilization
Circuit
Max
Total system Inrush
Current
per Branch
---------------- < 210A @ 208V, < 2ms ----------------------------
Total Input Power (W) 2298 4425 5443
Total Input VA 2344 4515 5554
Total Input Current (A)t 6.51 12.53 15.42
Input Current per cord
(A)
3.25 6.27 7.71
Total Airflow (CFM) 183 352 560
Total Airflow (CMM) 510 16
Heat Dissipating
Power (BTU)
7834 15088 18561
Table A-12. Electra VS G8 10RU fitted with 16 blades (AC NA Triple Phase @ 208VAC),
Electrical and Thermal specifications
Idle
@100%
Utilization
Circuit
Max
Total system Inrush
Current
per Branch
---------------- < 210A @ 208V, < 2ms ----------------------------
Total Input Power (W) 1676 5066 6342
Total Input VA 1710 5170 6472
Total Input Current (A)t 4.75 14.35 17.96
Input Current per cord
(A)
2.374 7.175 8.982
Total Airflow (CFM) 133 388 630
Total Airflow (CMM) 411 18
Heat Dissipating
Power (BTU)
5715 17277 21627
