Table A-13. Electra VS G9 10RU fitted with 16 blades (AC NA Triple Phase @ 208VAC),
Electrical and Thermal specifications
Idle
@100%
Utilization
Circuit
Max
Total system Inrush
Current
per Branch
---------------- < 210A @ 208V, < 2ms ----------------------------
Total Input Power (W) 1905 5575 6707
Tot al In pu t VA - 5690 -
Total Input Current (A)t - 15.79 -
Heat Dissipating
Power (BTU)
-19014 -
Table A-14. Electra VS G9 v210RU fitted with 16 blades (AC NA Triple Phase @ 208VAC),
Electrical and Thermal specifications
Idle
@100%
Utilization
Circuit
Max
Total system Inrush
Current
per Branch
---------------- < 210A @ 208V, < 2ms ----------------------------
Total Input Power (W)
1712
5231 6231
Total Input VA
-
5338 -
Total Input Current (A)t
-
14.82 -
Heat Dissipating Power
(BTU)
-
17839 -
Tab le A- 1 5 . Electra VS 10RU fitted with 16 blades ( AC NA Triple Phase @ 208VAC ),
Dimensions and Weight
Dimensions (H x W x D) 17.4 x 17.6 x 32 in / 442 x 447.04 x 813 mm
Weight 471 lbs / 213 kg
