Appendix A ’Technical Specifications’ — Hardware Delivery Specifications
488 Electra VS - Version 05.10
User Manual - Rev. A
Electra VS 10RU fitted with 8 system storage and processing blades
Table A-16. Electra VS G7 10RU fitted with 8 blades (AC NA Triple Phase @ 208VAC),
Electrical and Thermal specifications
Idle
@100%
Utilization
Circuit
Max
Total system Inrush
Current
per Branch
---------------- < 210A @ 208V, < 2ms ----------------------------
Total Input Power (W) 1389 2555 3130
Total Input VA 1418 2608 3194
Total Input Current (A)t 3.94 7.24 8.86
Input Current per cord
(A)
1.97 3.62 4.43
Total Airflow (CFM) 114 211 347
Total Airflow (CMM) 36 10
Heat Dissipating
Power (BTU)
4735 8710 10670
Table A-17. Electra VS G8 10RU fitted with 8 blades (AC NA Triple Phase @ 208VAC),
Electrical and Thermal specifications
Idle
@100%
Utilization
Circuit
Max
Total system Inrush
Current
per Branch
---------------- < 210A @ 208V, < 2ms ----------------------------
Total Input Power (W) 1073 2869 3582
Total Input VA 1095 2927 3655
Total Input Current (A)t 3.04 8.12 10.15
Input Current per cord
(A)
1.519 4.062 5.073
Total Airflow (CFM) 88 237 382
Total Airflow (CMM) 27 11
Heat Dissipating
Power (BTU)
3658 9782 12214
