Appendix A ’Technical Specifications’ — Hardware Delivery Specifications
Electra VS - Version 05.10 489
User Manual - Rev. A
Table A-18. Electra VS G9 10RU fitted with 8 blades (AC NA Triple Phase @ 208VAC),
Electrical and Thermal specifications
Idle
@100%
Utilization
Circuit
Max
Total system Inrush
Current
per Branch
---------------- < 210A @ 208V, < 2ms ----------------------------
Total Input Power (W) 1198 3084 3736.64
Tot al In pu t VA -3147 -
Total Input Current (A)t -8.73 -
Heat Dissipating
Power (BTU)
- 10515 -
Table A-19. Electra VS G9v2 10RU fitted with 8 blades (AC NA Triple Phase @ 208VAC),
Electrical and Thermal specifications
Idle
@100%
Utilization
Circuit
Max
Total system Inrush
Current
per Branch
---------------- < 210A @ 208V, < 2ms ----------------------------
Total Input Power (W) 1099 2914 3490
Total Input VA - 2974 -
Total Input Current (A)t -8.25 -
Heat Dissipating Power
(BTU)
- 9937 -
Table A-20. Electra VS 10RU fitted with 8 blades ( AC NA Triple Phase @ 208VAC ),
Dimensions and Weight
Dimensions (H x W x D) 17.4 x 17.6 x 32 in / 442 x 447.04 x 813 mm
Weight 357 lbs / 162 kg
