Chapter 3 ’Web User Graphical Interface’ — Workflow Library
Electra VS
-
Version 05.10 311
User Manual - Rev. A
H.264 AVC Encoder
Description
The
H.264 AVC encoder
processing component lets you encode video
in H.264 AVC format, 4:2:0, 8 bits, from low resolution up to HD.
Parameters
Figure 3-286. H.264 AVC encoder parameters
For this processing component, you must set the following parameters:
Rate mode
: indicate if the component bitrate should be
CBR
,
Capped
VBR
or
Statmux
. If set to
Capped VBR
, indicate the characteristics of
the video component, as shown hereafter.
Min bitrate
: indicate the minimum ES bitrate that the video
component should have.
Max bitrate
: indicate the maximum ES bitrate that the video
component should have.
When the input video is chunked, an IDR frame is set at the beginning
of the chunk. This overrides the configuration parameters.
Recommended settings can be found in section
’Recommended
Settings’
on page 392.
