Harmonic ELECTRA VS - State

Chapter 3 ’Web User Graphical Interface’ — GUI Description
Electra VS - Version 05.10 201
User Manual - Rev. A
You cannot modify the values in the array. To change the properties of a
job, click the
Show job details button.
State
Table 3-7 lists the possible states of the jobs and provides informations
about the states and the possible actions that you can perform.
By right-clicking on a redundant SDI job, a contextual menu allows
manual switch and switch back operations. The operations are
available only if
Automatic switch-back = On backup
failure
redundancy mode is selected. Refer to section
’Hardware/SDI Panel’ on page 188.
Table 3-7. Job states: colors, descriptions and possible actions
Job state
Description of the
state
Possible actions
Wait
The job has been
created and is waiting
before switching to
Running state.
 Duplicate
 Stop
 Show parameters
 Show workflow
 Export
 Import
Running
The job is being
executed.
 Duplicate
 Stop
 Show parameters
 Show workflow
 Export
 Import
 Switch (for redundant SDI job)
 Switch-back (for redundant SDI
job)
Completed
Job execution has
ended.
 Duplicate
 Start
 Show parameters
 Show workflow
 Delete
 Export
 Import
Stopped
The job has been
created but not started,
or started and then
stopped.
 Duplicate
 Start
 Show parameters
 Show workflow
 Delete
 Export
 Import
