Chapter 2 ’Installation and Startup’ — Hardware Delivery
52 Electra VS
-
Version 05.10
User Manual - Rev. A
2.
Go to the
Nodes
category.
3.
Check that:
All nodes present in the device are displayed in the list in the
GUI.
The status of each node is OK.
Performing the IP Configuration
1.
Select the
Setup
tab.
2.
Go to the
IP
category.
3.
Set the
Control
(X2 on 6RU and 10RU devices) network on the
control-command network:
If there are n nodes in the Electra VS, you need n consecutive
addresses, plus one for supervision.
Set the following parameters:
-
Address
-
Mask
-
Gateway (optional)
-
First address: first address of the n consecutive addresses
-
Supervision address
4.
Set the
Data 1
(X3 on 6RU and 10RU devices) network on the data
network:
If there are n nodes in the Electra VS, you need n consecutive
addresses.
Set the following parameters:
-
Address
-
Mask
-
Gateway (optional)
-
First address: first address of the n consecutive addresses
5.
Click
Apply
.
Preparing the Definitive Connection
Once you have made the IP configuration from the GUI:
1.
Disconnect the supervision PC from the GigE switch.
2.
Depending on the composition of the Electra VS:
If the Electra VS contains several 10RU blade centers or a mix of 1RU
and 10RU devices:
