Chapter 2 ’Installation and Startup’ — Hardware Delivery
Electra VS
-
Version 05.10 53
User Manual - Rev. A
Please refer to
Appendix F ’Heterogeneous System Configuration’
on page 579 for connection recommendations.
For a stand-alone blade server:
a.
Remove the SFP coupler from interface X1.
b.
Insert an SFP coupler on interfaces X2 and X3 of the two internal
switches of the blade center.
c.
Connect interfaces X2 on the control-command network, on a
single switch or two switches if redundancy is required.
d.
Connect interfaces X3 on the data network, on one unique
switch or on two switches if they are redunded.
For 1RU devices:
a.
Disconnect NIC 1 from the GigE switch.
b.
Depending on the hardware configuration:
1RU including two SD SDI octo boards
- Connect NIC 3 on the data network.
Other hardware configurations
- Connect NIC2 on the control-command network.
- Connect NIC3 on the data network.
Establishing the Definitive Connection
1.
From a supervision PC connected on the control-command network,
open a Web browser.
2.
Type in the address bar the supervision IP address that you configured
earlier and press
Enter
.
3.
Use the following account information:
Login:
admin
Password:
admin
You could perform the operation on one
internal switch of the
blade center
only but there would be no redundancy.
