Harmonic ELECTRA VS - Hardware Delivery Specifications

Appendix A ’Technical Specifications’ — Hardware Delivery Specifications
482 Electra VS - Version 05.10
User Manual - Rev. A
Hardware Delivery Specifications
Electrical, Thermal and Mechanical Specifications
For all specifications of your equipment, please refer to the HP Technical
Specifications provided on the DVD-ROM.
Values in the tables in this section are based on N + N redundancy mode
for the power supply, unless specified otherwise.
Electra VS 10RU
Electra VS 10RU (AC 200-240V single phase)
Electra VS 10RU fitted with 16 system storage and processing blades
Table A-1. Electra VS G7 10RU fitted with 16 blades (AC 200-240V single phase), Electrical
and Thermal specifications
Idle
@100%
Utilization
Circuit
Max
Total system Inrush
Current
--------------------- < 210A @ 230V, < 2ms -------------------------
Total Input Power (W) 2268 4429 5443
Total Input VA 2314 4519 5554
Total Input Current (A)t 10.06 19.65 24.15
Input Current per cord
(A)
1.68 3.27 4.02
Total Airflow (CFM) 180 352 560
Total Airflow (CMM) 510 16
Heat Dissipating
Power (BTU)
7734 15102 18561
Table A-2. Electra VS G8 10RU fitted with 16 blades (AC 200-240V single phase), Electrical
and Thermal specifications
Idle
@100%
Utilization
Circuit
Max
Total system Inrush
Current
--------------------- < 210A @ 230V, < 2ms -------------------------
Total Input Power (W) 1604 5035 6328
Total Input VA 1637 5137 6457
Total Input Current (A)t 7.12 22.34 28.07
