Harmonic ELECTRA VS - Page 483

Appendix A ’Technical Specifications’ — Hardware Delivery Specifications
Electra VS - Version 05.10 483
User Manual - Rev. A
Input Current per cord
(A)
1.186 3.723 4.679
Total Airflow (CFM) 128 386 628
Total Airflow (CMM) 411 18
Heat Dissipating
Power (BTU)
5470 17168 21577
Table A-3. Electra VS G9 10RU fitted with 16 blades (AC 200-240V single phase), Electrical
and Thermal specifications
Idle
@100%
Utilization
Circuit
Max
Total system Inrush
Current
--------------------- < 210A @ 230V, < 2ms -------------------------
Total Input Power (W) 1821 5565 6692
Tot al In pu t VA - 5678 -
Total Input Current (A)t - 24.69 -
Heat Dissipating
Power (BTU)
- 18976 -
Table A-4. Electra VS G9v2 10RU fitted with 16 blades (AC 200-240V single phase),
Electrical and Thermal specifications
Idle
@100%
Utilization
Circuit
Max
Total system Inrush
Current
---------------------<210A @ 230V, < 2ms>-----------------------
Total Input Power (W) 1611 5221 6218
Total Input VA - 5328 -
Total Input Current (A)t - 23.17 -
Heat Dissipating Power
(BTU)
- 17805 -
Table A-5. Electra VS 10RU fitted with 16 blades (AC 200-240V single phase), Dimensions
and Weight
Dimensions (H x W x D) 17.4 x 17.6 x 32 in / 442 x 447.04 x 813 mm
Weight 471 lbs / 213 kg
Table A-2. Electra VS G8 10RU fitted with 16 blades (AC 200-240V single phase), Electrical
and Thermal specifications
Idle
@100%
Utilization
Circuit
Max
