Appendix A ’Technical Specifications’ — Hardware Delivery Specifications
484 Electra VS - Version 05.10
User Manual - Rev. A
Electra VS 10RU fitted with 8 system storage and processing blades
Table A-6. Electra VS G7 10RU fitted with 8 blades (AC 200-240V single phase), Electrical
and Thermal specifications
Idle
@100%
Utilization
Circuit
Max
Total system Inrush
Current
--------------------- < 210A @ 230V, < 2ms -------------------------
Total Input Power (W) 1299 2535 3131
Total Input VA 1326 2587 3195
Total Input Current (A)t 5.77 11.25 13.89
Input Current per cord
(A)
0.96 1.87 2.31
Total Airflow (CFM) 106 210 347
Total Airflow (CMM) 36 10
Heat Dissipating
Power (BTU)
4431 8645 10672
Table A-7. Electra VS G8 10RU fitted with 8 blades (AC 200-240V single phase), Electrical
and Thermal specifications
Idle
@100%
Utilization
Circuit
Max
Total system Inrush
Current
--------------------- < 210A @ 230V, < 2ms -------------------------
Total Input Power (W) 973 2853 3574
Total Input VA 993 2911 3647
Total Input Current (A)t 4.32 12.66 15.86
Input Current per cord
(A)
0.720 2.109 2.643
Total Airflow (CFM) 80 236 381
Total Airflow (CMM) 27 11
Heat Dissipating
Power (BTU)
3320 9728 12188
Table A-8. Electra VS G9 10RU fitted with 8 blades (AC 200-240V single phase), Electrical
and Thermal specifications
Idle
@100%
Utilization
Circuit
Max
Total system Inrush
Current
--------------------- < 210A @ 230V, < 2ms -------------------------
Total Input Power (W) 1050 3075 3730
