Appendix A ’Technical Specifications’ — Hardware Delivery Specifications
Electra VS - Version 05.10 485
User Manual - Rev. A
Tot al In pu t VA -3137 -
Total Input Current (A)t - 13.64 -
Heat Dissipating
Power (BTU)
- 10484 -
Table A-9. Electra VS G9v2 10RU fitted with 8 blades (AC 200-240V single phase),
Electrical and Thermal specifications
Idle
@100%
Utilization
Circuit
Max
Total system Inrush
Current
--------------------- < 210A @ 230V, < 2ms -------------------------
Total Input Power (W) 947 2899 3485
Total Input VA - 2958 -
Total Input Current
(A)t
- 12.86 -
Heat Dissipating
Power (BTU)
- 9886 -
Table A-10. Electra VS 10RU fitted with 8 blades (AC 200-240V single phase),
Dimensions and Weight
Dimensions (H x W x D) 17.4 x 17.6 x 32 in / 442 x 447.04 x 813 mm
Weight 357 lbs / 162 kg
Table A-8. Electra VS G9 10RU fitted with 8 blades (AC 200-240V single phase), Electrical
and Thermal specifications
Idle
@100%
Utilization
Circuit
Max
