Harmonic ELECTRA VS - Page 578

Appendix F ’Network Settings’ — Hardware Delivery - 6RU and 10RU devices
578 Electra VS - Version 05.10
User Manual - Rev. A
Step 1: Reset the Flex10 configuration. To do this, open an SSH session
to the active Flex10, and enter successively the following commands:
 poweroff server *
 remove profile *
 delete domain
 import enclosure UserName=Administrator Password=xxxxxxx
(replace xxxxxxx by the password of the on-board administrator).
Step 2
: Apply the first part configuration file (use either C7000 or C3000
one, depending on your enclosure). This step automatically:
 Creates the 2 LANs that are absolutely necessary to the Electra VS:
System private LAN, and Internal data LAN.
 Creates a server profile that contains only these 2 LANs.
 Applies this server profile to the first blade of the enclosure.
Step 3
: Open the Web interface on the Flex10, and perform the following
actions:
1. Create the Shared Uplink Sets (SUS) you need.
2. Create the LANs you need: Control, data, etc.
3. Do not forget to configure correctly the external LANs: SmartLink and
Private Network feature shall be activated, and a LAN shall be
accessible by a blade on both NICs of a bond.
4. Edit the server profile, and configure it with the LANs you created.
Step 4
: Apply the last part configuration file. This step automatically:
 Creates new profiles identical to the first profile.
 Assigns these profiles to the other blades of the enclosure.
As usual, when the configuration is finished, save it carefully in a file (you
can use the "show config" command).
A LAN can be associated to an SUS at creation, but not after.
