Appendix A ’Technical Specifications’ — Hardware Delivery Specifications
Electra VS - Version 05.10 495
User Manual - Rev. A
Table A-33. Electra VS G9 10RU fitted with 16 blades (AC JPN Triple Phase @ 200VAC),
Electrical and Thermal specifications
Idle
@100%
Utilization
Circuit
Max
Total system Inrush
Current
per Branch
---------------- < 210A @ 200V, < 2ms ----------------------------
Total Input Power (W) 1905 5582 6714
Tot al In pu t VA - 5695 -
Total Input Current (A)t - 16.44 -
Heat Dissipating
Power (BTU)
- 19302 -
Table A-34. Electra VS G9v2 10RU fitted with 16 blades (AC JPN Triple Phase @ 200VAC),
Electrical and Thermal specifications
Idle
@100%
Utilization
Circuit
Max
Total system Inrush
Current
per Branch
---------------- < 210A @ 200V, < 2ms ----------------------------
Total Input Power (W) 1712 5236 6238
Total Input VA - 5343 -
Total Input Current (A)t - 15.42 -
Heat Dissipating Power
(BTU)
- 17856 -
Table A-35. Electra VS 10RU fitted with 16 blades ( AC JPN Triple Phase @ 200VAC ),
Dimensions and Weight
Dimensions (H x W x D) 17.4 x 17.6 x 32 in / 442 x 447.04 x 813 mm
Weight 470 lbs / 213 kg
