Appendix A ’Technical Specifications’ — Hardware Delivery Specifications
496 Electra VS - Version 05.10
User Manual - Rev. A
Electra VS 10RU fitted with 8 system storage and processing blades
Table A-36. Electra VS G7 10RU fitted with 8 blades (AC JPN Triple Phase @ 200VAC),
Electrical and Thermal specifications
Idle
@100%
Utilization
Circuit
Max
Total system Inrush
Current
per Branch
---------------- < 210A @ 200V, < 2ms ----------------------------
Total Input Power (W) 1357 2520 3090
Total Input VA 1385 2571 3153
Total Input Current (A)t 4.00 7.42 9.10
Input Current per cord
(A)
1.999 3.712 4.551
Total Airflow (CFM) 111 209 342
Total Airflow (CMM) 36 10
Heat Dissipating
Power (BTU)
4628 8593 10537
Table A-37. Electra VS G8 10RU fitted with 8 blades (AC JPN Triple Phase @ 200VAC),
Electrical and Thermal specifications
Idle
@100%
Utilization
Circuit
Max
Total system Inrush
Current
per Branch
---------------- < 210A @ 200V, < 2ms ----------------------------
Total Input Power (W) 1074 2871 3585
Total Input VA 1096 2930 3658
Total Input Current (A)t 3.16 8.46 10.56
Input Current per cord
(A)
1.582 4.228 5.280
Total Airflow (CFM) 88 238 382
Total Airflow (CMM) 27 11
Heat Dissipating
Power (BTU)
3662 9790 12224
