Chapter 3 ’Web User Graphical Interface’ — Operating Instructions (Tutorial)
136 Electra VS
-
Version 05.10
User Manual - Rev. A
2.
Perform the settings described in the table below.
3.
Apply the configuration.
Table 3-4. Settings to perform to encode a file
Processing
component
Parameter Action
TS file
input
TS file network
storage
Set the default value and set to public
TS file folder Set the default value and set to public
TS file name Set to public, label = "Input TS
filename"
TS video
extractor
Maximum format Set to
HD 1080i@25 fps
Program number Label = "Input PN"
PMT PID Label = "Input PMT PID"
Component PID Label = "Input video PID"
Codec Set to
Any
H.264 AVC
encoder
Bitrate Set to public, label = "Output video
bitrate"
Profile Set to
High
Frame structure Set to
Interlace
, public
TS audio
extractor
Program number Set to
First one
PMT PID Set to
Auto
Component PID Label = "Input audio PID"
Codec Set to
Any
MPEG-1
Layer 2
encoder
Bitrate Set to public, label = "Output audio
bitrate"
Stereo mode Set to
Stereo
TS
multiplexer
TS bitrate Set to 2,500,000 bps, public, label =
"Output TS bitrate"
TS
multiplexer
(input 1)
Component PID Make a link to "Input video PID"
a
a
To know how to make links between parameters, refer to section ’Link
Too l’ on page 236.
PMT PID Make a link to "Input PMT PID"
a
TS
multiplexer
(input 2)
Component PID Make a link to "Input audio PID"
a
TS file
output
TS file network
storage
Set the value
TS file folder Set the value
TS file name Make a link to "Input TS filename"
a
