Chapter 3 ’Web User Graphical Interface’ — Operating Instructions (Tutorial)
144 Electra VS
-
Version 05.10
User Manual - Rev. A
4.
Click
Save
.
5.
Now you can create instantiable workflows which embed the
sub-workflow ('
UM_Sub_WKF_AudioXCode
').
Figure 3-91. Example of workflow embedding the sub-workflows
The public parameters of the sub-workflow are visible and can be set as
public/private/protected in the main workflow.
Figure 3-92. Audio parameters in the main workflow
sub-workflow 'UM_Sub_WKF_AudioXCode'
