Figure 3-264. Video format converter parameters - Clipping
If the extracted region does not cover all the output video, then the rest
of the video is black.
When
Adaptive clipping
is used, then different configurations can be
applied depending on the input
Display Aspect Ratio
.
Figure 3-265. Video format converter parameters - Adaptive clipping
Position [0;0] is the top left corner.
Input video Output video
(Cropped area) X
(Cropped area) Y
(Cropped area)
size
(Insertion area) X
(Insertion area) Y
Output size
