Appendix A ’Technical Specifications’ — Common Specifications
Electra VS
-
Version 05.10 517
User Manual - Rev. A
I420: 4:2:0, 8 bits, planar (different from Microsoft definition)
Planar standard definition
The luma "luminance" plane Y appears first, then the U chroma
and last the V chroma planes as shown in the following diagram:
Supported image file formats:
Gif (fixed and animated)
Jpeg
Png
Tiff
Bmp (windows bitmap)
Tga (targa)
Remote file storage:
NFS v3
CIFS
YYYYYY
YYYYYY
YYYYYY
YYYYYY
U U U
U U U
V V V
V V V
