Key Description
Refer-
ence
Cursor A display setting and
movement
189
Compensation coefficient A
setting
303
Planar oscillation mode coeffi-
cient setting
249
Cursor A and cursor B display
settings and movement
189
Measurement halt at FAIL
judgment result setting
271
Absolute value mode setting 88, 95
Add segment 171
Compensation settings 21
Save only compensation value
with panel save function
318
Compensation type setting
274,
282
Draw after measurement ends
139,
269
ALL compensation settings
274,
282
Remove all panels from the
targets for continuous mea-
surement
266
Set all panels as targets for
continuous measurement
266
Loading all settings saved on a
USB flash drive
355
Save all saved data 351
Analyzer measurement 131
Area judgment range setting of
parameter 1
200
Drawing parameter setting
when area judgment
200
Setting the frequency range for
which to perform equivalent
circuit analysis
243
Auto range setting
49,
69,
161
Auto setting of save folder 344
Auto print setting 383
Auto setting of draw mode
(Automatically set upper and
lower limit values from set
measurement values)
184
To restore the colors of all seg-
ments to the initial state
182
Average setting
62,
80,
165,
169,
174
Susceptance (S) 25
Cursor B movement 190
Compensation coefficient B
setting
304
Planar oscillation mode coeffi-
cient setting
249
Display folder immediately
above
331
Beep settings
128,
234
BIN function settings 93
BIN function settings 84
Save copy of screen 341
Set handshake to hardware +
software
(Refer to the Communication
Instruction Manual (CD))
Delete last character
320,
325,
361
Cancel input
Cable length compensation 301
Panel compensation 308
Constant current sweep 135
Center value of sweep range
setting
146
Center value of vertical axis 185
Center value and width of ver-
tical axis settings
185
Center value of sweep range
and sweep width settings
146
Equivalent circuit settings 239
Configuring and executing
equivalent circuit analysis
253
Delete all input characters
320,
325,
361
Key Description
Refer-
ence
