ADSL WAN Connections
Viewing the Status and Configuration of Interfaces
Figure 7-16. show interfaces adsl Command
The “Link Status” indicates the training mode standard. If the ADSL interface
has established the Physical Layer, the “Line Type” and “Line Length” fields will
be populated with information about that particular ADSL connection. In
Figure 7-16, for example, the “Line Type” is Fast, and the “Line Length” is 933 feet.
!adsl 2/1 is UP, line protocol is UP
Link Status Up G.DMT
Line Type Fast
Line Length 933 ft
Downstream Upstream
Line Rate 8128 kbps 896 kbps
Current margin 10.0 dB 8.0 dB
Attenuation 1.0 dB 0.0 dB
Power 0 dBm 12 dBm
Prev Rate 0 kbps 0 kbps
Actual Delay 0 msecs 0 msecs
Loss of Framing Seconds 0 0
Loss of Signal Seconds 0 0
Loss of Power Seconds 0 0
Errored Seconds 0 0
Line Inits 1 N/A
Rx Blocks 7443 7443
Tx Blocks 7443 7443
Corrected Blocks 0 0
UncorrectedBlocks 0 0
Last Failure NONE
Last Failure Time N/A
DMT Bits Per Bin
000: 0 0 0 0 0 0 0 A B B C C B B B B
010: A A A B B B B B A A A 9 9 8 7 0
020: 0 2 4 5 7 7 8 9 9 A A A B B B B
030: C B C C C C C C C C C C C B B B
040: 0 B B B B B B B B B B B B B B B
050: B B B B B B B B B B B B B B B B
060: B B B B B B B B B A A A A A A A
070: A A A A A A A A A A A A A A A A
080: A A A A A A A A A A A A A A A A
090: A A A A A A 9 9 9 9 9 9 9 9 9 9
0A0: 9 9 9 9 9 9 9 9 9 9 9 9 9 9 9 9
0B0: 9 9 9 9 9 9 9 9 9 9 9 9 9 9 9 9
0C0: 9 9 9 9 9 9 9 9 9 9 9 9 9 9 9 9
0D0: 9 9 9 9 9 9 9 9 9 9 9 9 9 9 9 9
0E0: 9 9 8 9 9 8 9 9 9 9 9 9 9 9 9 9
0F0: 9 9 9 9 9 9 9 9 9 9 9 9 9 9 9 9
Status of physical and logical
interface
Training mode used
Actual downstream
and upstream rates
One indicator of
line condition
Watch
for
steadily
incre-
menting
losses or
errors
To Next Page
