Displays the MIDI channel.
To select a channel, tap at the plus or minus.
Device ID:
Displays the device ID.
To select a device ID, tap at the plus or minus.
Group ID:
Displays the group ID.
To select a group ID, tap at the plus or minus.
Ethernet Port:
Displays the Ethernet port.
To select a Ethernet port, tap at the plus or minus.
Mode:
Displays the MSC Mode.
By default, MSC Mode is disabled. To select a MSC mode, tap at the three dots in the edit line.
The drop-down list opens. There are three MSC modes available:
Disabled - MSC will not sent or received
Ethernet - MSC will sent or received via the selected Ethernet port
MIDI - MSC will sent or received via the MIDI connecter at the back of the console
Exec:
Displays the executor MSC commands.
By default, Main Only is selected. To select an executor, tap at the three dots in the edit line.
The drop-down list opens. There are three executor available:
Main Only - From or to the main executor.
Exec.Page - From or to a specified executor on page 1. Separated by a dot (Hex = 2E).
Exec Page - From or to a specified executor on page 1. Separated by a space (Hex = 20).
Command Format:
Displays the command format. The command format is used to indicate the type of equipment that is intended
to receive the MSC messages.
By default, All is selected. To select a command format, tap at the three dots in the edit line.
The drop-down list opens. There are three command formats available:
Moving Light - Format is Hex = 02
General Light - Format is Hex = 01
All - Format is Hex = 7F
Send to (only MSC Out):
