Figure 6: Gobo Preset
This is the gobo preset 3.6 (3 = Gobo Preset Pool, 6 = Object 6).
The gobo and the labeled name are displayed.
Example Color Preset
Figure 7:
Color Preset - Color Wheel
Figure 8: Color Preset - Mix Color
Figure 9: Color Preset - Color Wheel and Mix Color
This is the color preset 4.22 (4 = Color Preset Pool, Object = Tile 22).
A color preset from a color wheel is displayed as circle.
A color preset from a mix color is displayed as a quadrate.
A combined color preset from color wheel and mix color displays
in the big circle the actual color output
in the small circle the color from the color wheel
in the frame of the quadrate the color from the mix color.
The color and the labeled name are displayed.
