opens.
Page:
Displays the selected page.
To change the page, press and hold the cell or select the cell and press the scroll encoder. The Calculator opens.
Executor (only if the selected type is executor):
Displays the assigned executor number from the selected page to the input.
Hint:
To see the executor numbers in the executor bar, press and hold the key.
To select an executor, press and hold the cell or select the cell and press the scroll encoder. The Calculator opens.
If you typed in an invalid executor number, the executor cell is displayed with a red background.
Function (only if the selected type is executor):
Displays the assigned button or fader.
To select a button or fader, press and hold the cell or select the cell and press the scroll encoder. The Select
Function Window opens.
CMD (= command, only if the selected type is CMD):
Displays the assigned command to the input.
To type in a command, press and hold the cell or select the cell and press the scroll encoder. The virtual keyboard
opens. Enter the command which should be executed.
Analog
For using the analog remote you have to connect e.g. a light barrier or a push button, on the DC Remote Control
at the back of the console.
Refer to, physical setup and layout.
Additional to the four standard columns, the analog remote control has the Input column.
Input:
Displays the input in from the connected DC Remote Control.
The pin layout is displayed next to the connector on the back of the console.
Pin 1 - 6 = Input 1,3,5,7,9,11
Pin 9 - 14 = Input 2,4,6,8,10,12
There are twelve different inputs available to assign.
This column is read only.
MIDI
