I
Instances:
Single controls of the fixture types, e.g. one pixel of a LED panel. Refer to, Import Fixture Type... Window.
Iris:
An aperture that controls the beam size of a fixture.
M
Macro:
Prerecorded command combinations.
Master Rate:
The master rate multiplies all timings by a factor.
The factors from the master rate goes from Stop (= no further output) via 1:1 (=stored timings) up to 256
(=multiplies the timing by 256).
The master rate is a dynamic fader that means, if that fader has the position of 50 % the rate fader has the factor
1:1. From 1:1 the fader goes dynamic up to 256 that equates a fader position from 100 %. It is the same from 1:1
down to Stop.
Master Speed:
Controls the speed of effects in cues and the playback speed of chasers.
MIDI (musical instrument digital interface):
A standard to exchange control signals with the console. Refer to, Remote Inputs Configuration Window.
MSC (MIDI Show Control):
MSC sends the executor functions via MIDI signal to another device, e.g. another console or a MIDI sequencer.
Refer to, MIDI Show Control Window.
N
Natural Values:
The dot2 displays all raw channel views in natural values with one decimal place.
Usually the range is from 0 to 100 and equates the DMX values from 0 to 255.
Exception: The range from pan is -270 to 270 and from tilt is -125 to 155.
O
