Ricoh Aficio MP C3501 Service Manual

System SP2-xxx
D086/D087 3-42 SM Appendix
015 PCU:Thick 2&FINE *ENG
[–100 to 100 / -28 / 1 –V/step]
016 HVP:Plain *ENG
[–100 to 100 / 20 / 1 –V/step]
017 HVP:Thick 1 *ENG
[–100 to 100 / 20 / 1 –V/step]
018 HVP: Thick 2&FINE *ENG
[–100 to 100 / 29 / 1 –V/step]
2006
[Charge AC Voltage] Charge Roller AC Voltage Adjustment
(Paper Type, Process Speed, Color)
Paper Type –> Plain, Thick 1, Thick 2
Plain: High speed, Thick 1: Middle speed, Thick 2&FINE: Low speed
Adjusts the AC component of the charge roller bias in the various print modes.
Charge bias (AC component) is adjusted by environment correction
(SP2-007-xxx to SP2-011-xxx). These SPs are activated only when SP2-012-1
is set to "1: manual control".
001 Plain: Bk *ENG
[0 to 3 / 1.9 / 0.01 KV/step]
002 Plain: M *ENG
[0 to 3 / 2.2 / 0.01 KV/step]
003 Plain: C *ENG
[0 to 3 / 2.2 / 0.01 KV/step]
004 Plain: Y *ENG
[0 to 3 / 2.2 / 0.01 KV/step]
005 Thick 1: Bk *ENG
[0 to 3 / 1.9 / 0.01 KV/step]
006 Thick 1: M *ENG
[0 to 3 / 2.2 / 0.01 KV/step]
007 Thick 1: C *ENG
[0 to 3 / 2.2 / 0.01 KV/step]
008 Thick 1: Y *ENG
[0 to 3 / 2.2 / 0.01 KV/step]
009 Thick 2&FINE: Bk *ENG
[0 to 3 / 1.9 / 0.01 KV/step]
010 Thick 2&FINE: M *ENG
[0 to 3 / 2.2 / 0.01 KV/step]
011 Thick 2&FINE: C *ENG
[0 to 3 / 2.2 / 0.01 KV/step]
012 Thick 2&FINE: Y *ENG
[0 to 3 / 2.2 / 0.01 KV/step]

Ricoh Aficio MP C3501 Specifications

General

Print Technology	Laser
Print Speed (Color)	35 ppm
Print Speed (Monochrome)	35 ppm
Maximum Print Resolution	1200 x 1200 dpi
Standard Paper Capacity	1, 200 sheets
Maximum Paper Capacity	4, 400 sheets
Duplex Printing	Yes
Maximum Scan Resolution	600 dpi
Copier Resolution	600 dpi
Fax Capability	Optional
Memory (Maximum)	1.5 GB
Network Connectivity	Ethernet
Connectivity	USB 2.0, Ethernet 10/100Base-TX
Functions	Print, Copy, Scan
Hard Disk Drive	160 GB
Scan Speed	50 ipm
Operating System Compatibility	Windows, Mac, Linux
