Ricoh Aficio MP C3501

Paper Transfer
D086/D087 4-76 SM
Cleaning for ID sensors
ID sensors require a cleaning procedure every EM. Do the following steps for ID sensor
cleaning.
1. K PCDU (
p.4-49)
2. Fusing unit (
p.4-99)
3. Image transfer belt unit (
p.4-63)
4. Slide the ID sensor shutter [A] to the left side.
5. Clean the ID sensors keeping the ID sensor shutter to the left.
