Ricoh Aficio MP C3501

GENERAL LAYOUT
B408 10 SM
4. DETAILED DESCRIPTIONS
4.1 GENERAL LAYOUT
1. Upper Tray
2. Upper Tray Exit Roller
3. Entrance Roller
4. Tray Junction Gate
5. Upper Transport Roller
6. Stapler Junction Gate
7. Lower Transport Rollers
8. Stapler
9. Stack Feed-out Belt
10. Positioning Roller
11. Shift Roller
12. Lower Tray
13. Lower Tray Exit Roller
B408D101.WMF
1
2
3
4
5
6
7
8
9
10
11
12
13
