Ricoh Aficio MP C3501 Service Manual

SM i D086/D087
D086/D087
TABLE OF CONTENTS
PRODUCT INFORMATION
1. PRODUCT INFORMATION .......................................................... 1-1
1.1SPECIFICATIONS ...................................................................................... 1-1
1.2PRODUCT OVERVIEW .............................................................................. 1-2
1.2.1 COMPONENT LAYOUT .................................................................... 1-2
1.2.2 PAPER PATH .................................................................................... 1-3
1.2.3 DRIVE LAYOUT ................................................................................ 1-4
1.3MACHINE CONFIGURATION .................................................................... 1-6
1.4GUIDANCE FOR THOSE WHO ARE FAMILIAR WITH PREDECESSOR
PRODUCTS.................................................................................................... 1-10
INSTALLATION
2. INSTALLATION ............................................................................ 2-1
2.1INSTALLATION REQUIREMENTS ............................................................ 2-1
2.1.1 ENVIRONMENT ................................................................................ 2-1
2.1.2 MACHINE LEVEL .............................................................................. 2-2
2.1.3 MACHINE SPACE REQUIREMENTS ............................................... 2-2
2.1.4 MACHINE DIMENSIONS .................................................................. 2-3
2.1.5 POWER REQUIREMENTS ............................................................... 2-3
2.2OPTIONAL UNIT COMBINATIONS ............................................................ 2-4
2.2.1 MACHINE OPTIONS ......................................................................... 2-4
2.2.2 CONTROLLER OPTIONS ................................................................. 2-6
2.2.3 OTHER OPTIONS ............................................................................. 2-7
2.2.4 FAX OPTIONS ................................................................................... 2-7
2.3COPIER INSTALLATION ............................................................................ 2-8
2.3.1 POWER SOCKETS FOR PERIPHERALS ........................................ 2-8
2.3.2 INSTALLATION FLOW CHART ......................................................... 2-9
2.3.3 INSTALLATION PROCEDURE ....................................................... 2-10
Tapes and Retainers ........................................................................... 2-10
Developer and Toner Bottles .............................................................. 2-11
Paper Trays ........................................................................................ 2-12

Ricoh Aficio MP C3501 Specifications

General

Print Technology	Laser
Print Speed (Color)	35 ppm
Print Speed (Monochrome)	35 ppm
Maximum Print Resolution	1200 x 1200 dpi
Standard Paper Capacity	1, 200 sheets
Maximum Paper Capacity	4, 400 sheets
Duplex Printing	Yes
Maximum Scan Resolution	600 dpi
Copier Resolution	600 dpi
Fax Capability	Optional
Memory (Maximum)	1.5 GB
Network Connectivity	Ethernet
Connectivity	USB 2.0, Ethernet 10/100Base-TX
Functions	Print, Copy, Scan
Hard Disk Drive	160 GB
Scan Speed	50 ipm
Operating System Compatibility	Windows, Mac, Linux
