LCIT RT3010 (D539)
SM 2-33 D086/D087
Installation
2.8.2 INSTALLATION PROCEDURE
Unplug the main machine power cord before starting the following procedure.
The Paper Tray Unit (D537) or LCT 2000-sheet (D538) must be installed before
installing this 1200-sheet LCT.
1. Unpack the LCT and remove the tapes.
2. Remove the stand covers [A].
3. Release the locks [B] of the front and rear caster stands.
4. Remove the caster stands [C].
5. Remove the paper path cover [A], connector cover [B] and six hole covers [C].
