Ricoh Aficio MP C3501

Electrical Components
D541 10 SM
1.3.4 ORIGINAL SIZE SENSORS AND SKEW CORRECTION
SENSOR
1. Original feed-in guide plate (see "Original Set Sensor")
2. Original turn guide plate [A] (hook x 1).
3. Original width sensors [B] (
x 1 each) and skew correction sensor [C] with bracket (
x 1,
x 1)
