Ricoh Aficio MP C3501

Folder
SM 17 B793
B793
Booklet
Finisher
1.3.3 FOLDER UNIT EXIT SENSOR
1. Remove the folder unit.
2. Remove the folder unit upper cover [A] (
x 1).
3. Remove the lower clamp roller unit [B] (
x 4).
4. Remove the folder unit exit sensor [C] (
x 1, x 1).
