Ricoh Aficio MP C3501 Service Manual

JAM DETECTION
B408 8 SM
2. TROUBLESHOOTING
2.1 JAM DETECTION
Mode
Shift Staple
Jam Con
tent
 
Entrance sensor:
On check
The entrance sensor does not turn on
within the normal time after the main
machine exit sensor turns on
 
Entrance sensor:
Off check
The entrance sensor does not turn off
within the normal time after it turns on.

Lower tray exit sensor:
On check
The lower tray exit sensor does not turn
on within the normal time after the
entrance sensor turns off.

Tray exit sensor:
Off check
The tray exit sensor does not turn off
within the normal time after it turns on.

Stapler tray entrance sensor:
On check
The stapler tray entrance sensor does
not switch on within the normal time
after the entrance sensor switched on.

Stapler tray entrance sensor:
Off check
The staple tray entrance sensor does
not turn off within the normal time after it
turns on.

Lower tray exit sensor:
On check
The lower exit sensor does not turn on
after the feed-out pawl feeds out the
outputs.

Lower tray exit sensor:
Off check
The lower exit sensor turns on when the
feed-out pawl returns to its home
position after feeding out the outputs.
