Ricoh Aficio MP C3501

Card Reader Bracket Type C5501 (D547)
SM 2-89 D086/D087
Installation
2.23 CARD READER BRACKET TYPE C5501 (D547)
2.23.1 COMPONENT CHECK
Check the quantity and condition of the accessories against the following list.
No. Description Q’ty
1 Screw: M3 x 8 2
2 Screw: M3 x 14 1
3 Screw: M3 x 25*
1
1
4 Tapping Screw: M3 x 10 3
5 Upper Tray 1
6 Lower Tray 1
7 Tray Bracket 1
8 Clamp 5
*1: Not used in this machine
