Ricoh Aficio MP C3501 Service Manual

DIP Switches
B793 30 SM
1.5 DIP SWITCHES
SW100: Adjust the staple position for booklet mode
No. Function
1 ON: 0.3 mm
2 ON: 0.6 mm
3 ON: 1.2 mm
4
Direction
OFF: Towards the trailing edge, ON: Towards the leading edge
SW101: Adjust the fold position
No. Function
1 ON: 0.2 mm
2 ON: 0.4 mm
3 ON: 0.8 mm
4
Direction
OFF: Towards the trailing edge, ON: Towards the leading edge
SW102: Move the tray position
No. Function
1
OFF → ON → OFF
Turn the switch from off to on, then turn it to off again. Then, the tray moves down to
the shipping position
2 Not used
 After you change any of these dip switch settings, open and close the finisher
cover to activate the new setting. It is not necessary to turn the main power off/on.

Ricoh Aficio MP C3501 Specifications

General

Print Technology	Laser
Print Speed (Color)	35 ppm
Print Speed (Monochrome)	35 ppm
Maximum Print Resolution	1200 x 1200 dpi
Standard Paper Capacity	1, 200 sheets
Maximum Paper Capacity	4, 400 sheets
Duplex Printing	Yes
Maximum Scan Resolution	600 dpi
Copier Resolution	600 dpi
Fax Capability	Optional
Memory (Maximum)	1.5 GB
Network Connectivity	Ethernet
Connectivity	USB 2.0, Ethernet 10/100Base-TX
Functions	Print, Copy, Scan
Hard Disk Drive	160 GB
Scan Speed	50 ipm
Operating System Compatibility	Windows, Mac, Linux
